Description
1. High brightness customized 1000nits-3500nits, anto-dimming sensor
High brightness with 2500nits to be sunlight readable for outdoor use, the auto-dimming sensor
will change the brightness from the ambient light
2. Industrial grade 110℃ high temperature resistant panel
3. Full optical bonding in front of the screen
4. IP65 waterproof level
5. Intelligent temperature control, cooling fan
6. Can be spliced in single screen/two screen/triple screen, widely use for restaurant and food shop
Parameter
| Model | FSOD490-D25-T |
| Panel | Size | 49" |
| Panel Technology | IPS |
| Aspect Ratio | 16:9 |
| Resolution | 1920*1080 |
| Brightness | 2500nits |
| Contrast Ratio | 1200:1 |
| Viewing Angle | 178/178 |
| Surface Treatment | Haze 3% |
| Lifetime | 50000Hrs |
| Display Mode | Horizontal/Vertical |
| Physical Appearance | Color | Black |
| Material | Aluminum,Galvanized Iron Plate |
| Surface Treatment | Outdoor Powder |
| Outline Dimension | 1147*677*95.5mm |
| N.W. | 36KG |
| Package Dimension | 1250*800*220mm |
| G.W. | 44kg |
| Mounting Hole | VESA1075*400mm |
| Operation Environment | OP temperature | -20--50℃ |
| OP Humidity | 10%--85% |
| IP level | IP65 |
| Protective Glass | 5mm Ultra-Clear Glass |
| Mainboard | SPEC | 8-core CPU A55 Android 12.0 2+16GB |
| | Interface | HDMI*1 USB*2 RJ45*1 WIFI*1 |
| Power | Input | 180-264V, 50/60Hz |
| Max Power Consumption | 240W |
FAQ
1.Q: Are you a manufacturer or trading company?
A: We are a professional manufacturer specialized in LCD panel/LCM since 2016 located in Shenzhen.
2. Q: How long is the warranty?
A: Our officially promised warranty time is 1 year or 18months(Non-artificial damages) from the date of
delivery.
3. Q: Do you provide ODM/OEM or customized service?
A: We’re BOE High-bright LCD ODM factory, OEM/ODM are available based on your requirements.
In order to support different customers, we are able to supply:
(1) High Brightness LCD Panel: LCD panel+led driver board+auto dimming sensor
(2) Open Frame LCD Displays: LCD Panel+PSU+AD board(optional interface, eg: HDMI, VGA, DVI,
USB...)+Touch optional
(3) Window Facing Displays: LCD Panel+PSU+AD board (network board optional)+fan system+tem-
perature control board+housing
(4) Full Outdoor Displays: customized. eg: touch function, IP55/IP65 etc.
4. Q: What brand of OC do you use?
A: Original LG/SAMSUNG/AUO/BOE etc. A or A+ grade OC, we can guarantee each display will pass
through strict quality inspection.
5. Q:What certifications you have?
A:The CE-EMC Certificate of Conformity, ISO certification, FCC certification.
6.Q:What is the temperature when the screen surface goes black?
A: Normal grade goes black over 68℃；industrial grade goes black over 105 or 110℃.
7.Q: What is the MOQ?
A: Sample testing is acceptable, the price is negotiable for bulk order.
8.Q: When will you delivery?
A: High brightness LCD panel sample order shipped in 3days, bulk order shipped within 2 weeks.
